بررسی آسیب دز یونساز کل در مدار ارتفاع کم با استفاده از داده‌های دریافت شده از محموله‌های تشعشعی یک میکروماهواره

نوع مقاله : مقاله پژوهشی

نویسندگان
1 پژوهشکده سامانه های ماهواره، پژوهشگاه فضایی ایران، تهران، ایران
2 پژوهشکده سامانه های ماهواره، پژوهشگاه فضایی ایران، تهران، ایران.
10.22034/jssta.2025.511720.1237
چکیده
محیط تشعشعی ماموریت‌های فضایی عامل بروز آسیب‌های متنوعی بر مواد و قطعات الکترونیکی استفاده شده در فضاپیماها می‌باشد. این آسیب‌ها تاکنون منشاء بروز خرابی‌های متعدد و حتی از دست رفتن کامل چندین ماموریت‌ فضایی بوده‌اند. براین اساس شناسایی این محیط از حیث توع، انرژی و شار پرتوها بسیار اهمیت داشته و کمک شایانی به طراحان تجهیزات فضایی به منظور جبران یا کاستن اثرات مخرب این محیط پرتویی خواهد داشت. به همین دلیل از سال‌های آغازین ارسال ماهواره به فضا تاکنون استفاده از محموله‌های تشعشعی برای شناسایی این محیط و مدل‌سازی آن ادامه داشته است. این مقاله به تحلیل داده‌های یک میکروماهواره عملیاتی میپردازد که با هدف تثبیت چندین فناوری به فضا پرتاب شده است. محموله اصلی این ماهواره دو عدد دزیمتر برای اندازه‌گیری دز یونساز کل در مدار LEO است. براساس داده‌های دریافتی از ابتدای پرتاب ماهواره تاکنون (به مدت یکسال) مقدار دز یونساز کل در داخل و خارج از ماهواره به ترتیب برابر rad 65 و krad1 بوده است. با انجام شبیه‌سازی، مقدار ضخامت حفاظ معادل با پلتفرم ماهواره برابر 10 میلیمتر آلومینیوم می‌باشد. علاوه بر این داده‌های اخذ شده از ماهواره به خوبی تاثیر دو طوفان خورشیدی از مرتبه G5 را که طی مدت فوق رخ داده‌اند را ثبت و نشان می‌دهد که هر طوفان خورشیدی می‌تواند مقدار دز را برای قطعات نصب شده در بیرون از ماهواره طی چند روز بیش از rad300 افزایش دهد.
کلیدواژه‌ها
موضوعات

[1]  R. H. Maurer, M. E. Fraeman, M. N. Martin, and D. R. Roth, “Harsh environments : space radiation environment, effects, and mitigation,” Johns Hopkins APL technical digest, vol. 28, no. 1, pp. 17–29, Jan. 2008.
[2]  I. Lopez-Calle, and A.I. Franco, “Comparison of cubesat and microsat catastrophic failures in function of radiation and debris impact risk,” Scientific Reports, vol. 13, no. 1, Jan. 2023, doi: https://doi.org/10.1038/s41598-022-27327-z.
[3]  C. Granja, S. Polansky, Z.  Vykydal, S. Pospisil, A. Owens, Z. Kozacek, K. Mellab, and M. Simcak, “The SATRAM Timepix spacecraft payload in open space on board the Proba-V satellite for wide range radiation monitoring in LEO orbit,” Planetary and Space Science, vol. 125, pp. 114-129, 2016. https://doi.org/10.1016/j.pss.2016.03.009.
[4] Y. Sun et al., “Radiation Dose Detection on FY-4B Satellite,” Aerospace, vol. 10, no. 4, pp. 325–325, Mar. 2023, doi: https://doi.org/10.3390/aerospace10040325.
[5] V.I. Osedlo, V.V. Kalegaev, I.A. Rubinshtein, V.I. Tulupv, A.A. Shemukhin, N.N. Pavlov, O.I. Abanin, I.A. olotarev, V.O. Barinova, V.V. Bogomolov, N.A. Vlasova, I.N. Myagkova, and E.A. Ginburg, “Monitoring the radation stateof the Near the Earth Space on the Arktika-M No.1 Satellite,” Cosmic research, vol. 60, no. 6, pp. 406-419, 2022.
[6]  R.J. Casurellas, C. Araguz, P. Via, A. Solanellas, A. Amézaga, D. Vidal, et al. , “3Cat-1 project: a multi-payload CubeSat for scientific experiments and technology demonstrators,” European Journal of Remote Sensing, vol. 50, no. 1, pp. 125–136, 2017. https://doi.org/10.1080/22797254.2017.1274568
[7]  S. Svertilov et al., “Monitoring of Radiation Fields in Near Earth Space and Atmosphere in New Space Projects of Moscow University,” E3S Web of Conferences, vol. 196, p. 02019, 2020, doi:https://doi.org/10.1051/e3sconf/ 202019602019.
[8]  J.J. Likar, S.E. Stone, R.E. Lombardi, and K.A. Long, “Novel radiation design approach for CubeSat based missions,” in Proceedings of the AIAA USU Conference of Small Satellite., 2010.
[9]  J. Dijks, Precise LEO Space Radiation Monitoring using the Space RadMon-NG Payload, CERN Document Server, 2023. https://cds.cern.ch/record/2850822?ln=en (accessed Feb. 28, 2025).
[10] M. Meguellati, F. Djeffal, D. Arar, T. Bendib, and L. Khettache, “RADFET dosimeter design for environment monitoring applications,” in: Proceedings of the 24th International Conference on Microelectronics (ICM), Algiers, Algeria, 2012.
[11] S.-J. Kim, K.-W. Min, D. Ko, and J. Seon, “Use of a MOSFET for radiation monitoring in space and comparison with the NASA trapped particle model,” Journal of the Korean Physical Society, vol. 48, no. 4, pp. 865–869, Apr. 2006.
[12] F. Ravotti, Response of RadFET Dosimeters to High Flounces of Fast Neutrons, IEEE Transactions on Nuclear Science,” IEEE Transactions on Nuclear Science, vol. 52, no. 4, pp. 335-339, Augest 2005, doi: 10.1109/NSSMIC.2004.1462208.
[13] M. Pejovic, “P-channel MOSFET as a sensor and dosimeter of ionizing radiation,” Facta universitatis - series: Electronics and Energetics, vol. 29, no. 4, pp. 509–541, 2016, doi: https://doi.org/10.2298/fuee1604509p.
[14] L. Ratti, Ionizing Radiation Effects in Electronic Devices and Circuits, INFN Laboratori Nazionali di Lgnaro, Legnaro, 2013.
[16] A. Holmes-Siedle and L. Adams, “The Mechanisms of Small Instabilities in Irradiated MOS Transistors,” IEEE Transactions on Nuclear Science, vol. 30, no. 6, pp. 4135–4140, 1983, doi: https://doi.org/10.1109/tns.1983.4333096.
[17] I. Jun, H. Garrett, W. Kim, Y. Zheng, S.F. Fung, C. Corti, N. Ganushkina, and J. Guo, “A review on radiation environment pathways to impacts: Radiation effects, relevant empirical environment models, and future needs,” Advances in Space Research, 2024, doi: 10.1016/j.asr.2024.03.079.
[18] R. Amajdifard, F. Bagheroskouei, and O. Shekoofa, “Design, Implementation and Test of a Space Qualified Dosimeter for Total Ionizing Dose Measurement,” Journal of Nuclear Science and Technology, vol. 99, no. 2, pp. 1-9, 2022.
[19] M. Sajid, N.G. Chechenin, F.S. Torres, M.N. Hanif, U.A. Gulzari, S. Arslan, and E.U. Khan, “Analysis of Total Ionizing Dose effects for highly scaled CMOS devices in Low Earth Orbit,” Nuclear Instruments and Methods in Physics Research Section B: Beam Interactions with Materials and Atoms, vol. 428, pp. 30-37, 2018.
[20] R. Miteva and S. W. Samwel, “Catalog of Geomagnetic Storms with Dst Index ≤ −50 nT and Their Solar and Interplanetary Origin (1996–2019),” Atmosphere, vol. 14, no. 12, pp. 1744–1744, Nov. 2023, doi: https://doi.org/10.3390/atmos14121744.
[21] J. Matzka, C. Stolle, Y. Yamazaki, O. Bronkalla, and A. Morschhauser, “The Geomagnetic Kp Index and Derived Indices of Geomagnetic Activity,” Space Weather, vol. 19, no. 5, May 2021, doi: https://doi.org/10.1029/2020sw002641.



دوره 6، شماره 1
مهر 1405
صفحه 50-60

  • تاریخ دریافت 21 اسفند 1403
  • تاریخ بازنگری 23 فروردین 1404
  • تاریخ پذیرش 22 تیر 1404
